Sabfoil Kit BALZ 909-663-370/83BALZ/MK83 – BALZ/W909 – F663K – SF/370 – CP02K/Ti

SABFOIL-25-157

WING FOIL
Foil Set BALZ PRO 909-663-370/83
Sabfoil Balz Müller hydrofoil Pro set

BALZ/MK83- BALZ/W909- SF/370- F663K – CP02K/Ti

Bag and Q02K included
Foil Set BALZ PRO 909-663-370/83 specs
TOP SPEED
LIFT
GLIDE
MANEUVERABILITY
PUMPING
Range Balz PRO
Recommended for Freestyle Pro – Freestyle – Freeride – Wave – Fast Freeride
Take Off Speed 10 – 12 kn
Top End Speed (average 80kg user) 25 – 27 kn

Introducing the Balz Pro Line, Balz Müller?s signature model for Sabfoil for riders seeking unparalleled performance. Engineered for explosive acceleration and high top speeds, this wing delivers exceptional pop and precision, making it ideal for funboarding sessions that include advanced aerial maneuvers and smooth, skaty carves.

The Balz Pro version elevates performance even further with an increased surface area at the center, ensuring smooth low-speed takeoffs, and a refined dihedral angle that provides unmatched control and responsiveness during consecutive jumps. Additionally, the foil effectively catches landings, offering an astonishing rebound that enhances your riding experience. The twist at the tips guarantees exceptional stability, whether you?re carving through high-speed waves or navigating challenging conditions.

This set comes with the smallest front wing 909 and flat stabilizer 370, for the best control and power while wing foiling in medium-low conditions.

As Balz Müller himself states, the new Pro Line foil excels on all fronts: it offers an effortless ride, versatility in all conditions, and durability that stands the test of time. Experience the thrill and reliability that only the Balz Pro Line can deliver?a foil designed to push your limits and elevate your ride to pro-level performance!

Bag and Titanium Quick Release System (Q02K) included

Dimensions & Advanced specs
Front Wing – Span 909 mm
Front Wing – Surface 1000 cm2
Front Wing – Volume 874,4 cm3
Front Wing – Aspect Ratio 8,26
Front Wing – Root Chord 161 mm
Front Wing – Maximum Thickness 17 mm
Stabilizer – Span 370 mm
Stabilizer – Surface 195 cm2
Stabilizer – Volume 85 cm3
Stabilizer – Aspect Ratio 7,00
Stabilizer – Root Chord 67,5 mm
Stabilizer – Maximum Thickness 7,3 mm
Fuselage – Length 663 mm
Mast – Height 830 mm
Mast – Board Connection Carbon Plate
Foil Set – Weight (ca.) 4,15 kg
Content
Sabfoil Kraken Mast 83 Balz Müller Limited | Hydrofoil Mast x 1
BALZ/MK83

Sabfoil 909 Balz Müller Limited | T8 Hydrofoil Front Wing x 1
BALZ/W909

Sabfoil Flat 370 | Hydrofoil Stabilizer x 1
SF/370

Fuselage 663 T8/R8 x 1
F663K

Sabfoil Carbon Rail Plate with Titanium Inserts x 1
CP02K/Ti

Hardware Kit WMP669/WMP769/WMP869 x 1
MH165

Hardware Kit S330Y/S370/S376/S399/S400/SRD339/SRD379 x 1
MH107

Hardware Kit F663K/F703K/F753K/F903K/F1003K x 1
MH138

Spare Titanium Pin and Shims for Q02K x 1
MHQ02

Foam Pads for Plate x 1
MH144

Allen Keys, Torx Keys and Lithium Grease x 1
MH137

Hardware Kit Carbon Plate to Rail Board x 1
MH160

Shim Set for Fuselages -0,5°/-1°/-1,5°/-2°/-2,5°/-3° x 1
MHW060

Sabfoil Hydrofoil Bag L x 1
MA008
