Sabfoil Stabilizer Reverse 395198 cm2 – AR 8,08

SABFOIL-25-244

Sabfoil Reverse 395 | Hydrofoil Stabilizer
MAIN SPECS

Surface: 198 cm2

AR: 8,08

Wingspan: 400 mm

Chord: 64,96 mm
Sabfoil Reverse 395 | Hydrofoil Stabilizer specs
STABILITY
MANEUVERABILITY
SPEED
Range Reverse
Stabilizer-Fuselage Connection Standard
Recommended with front wings 600 – 1400 cm2

Thanks to the slim profile and the accentuated reverse dihedral angle, this stabilizer is designed for those looking for excellent performance in terms of speed and directionality. The design also provides great maneuverability and makes it ideal for carving.

The S395/PF is hand sanded to achieve a matte surface with 0-thickness graphics, the SAB Pro Finish, for an elegant Made in Italy product with maximum performance.

Dimensions & Advanced specs
Stabilizer – Span
400 mm
Stabilizer – Surface
198 cm2
Stabilizer – Root Chord
64,96 mm
Stabilizer – Aspect Ratio
8,08
Stabilizer – Maximum Thickness
7,21 mm
Stabilizer – Volume
87 cm3
Stabilizer – Weight (ca.)
134,5 g
Stabilizer – Material
Full Carbon (coreless)
Content
Sabfoil Reverse 395 | Hydrofoil Stabilizer x 1
SR/395

Hardware Kit S325/S355/S375/S380/S395/S425/S430/S450/S480/S483 x 1
MH108
