Sabfoil W590Y – Sabfoil 590Y – IKA Youth Foil Class | T6 Hydrofoil Front Wing

KITE FOIL
Sabfoil 590Y – IKA Youth Foil Class | T6 Hydrofoil Front Wing

MAIN SPECS

Surface: 650 cm2

AR: 5,20

Wingspan: 590 mm

Chord: 132 mm

IKA YOUTH FOIL CLASS Registered

Certifications IKA – Youth Foil Class
Disciplines Kite
Wing-Fuselage Connection T6
Recommended for Freeride – Race
Take Off Speed 13 – 15 kn
Top End Speed (average 80kg user) 30 kn ?

The W590Y is a fast and stable wing, has very smooth acceleration, is quick in glide, and tracks naturally.

Suitable for all riders who want a full-performance wing.

With its 650 cm2 of surface area, it allows lift even at low speeds, while the slightly inverted design maintains the stability needed at high speeds. A very easy wing to steer, with a good upwind angle and capable of exceeding 30 knots. Being very stable and predictable, the W590Y is also ideal for beginners.

IKA YOUTH FOIL CLASS Registered

Dimensions & Advanced specs
Front Wing – Span
590 mm
Front Wing – Surface
650 cm2
Front Wing – Root Chord
132 mm
Front Wing – Aspect Ratio
5,20
Front Wing – Maximum Thickness
Front Wing – Volume
Front Wing – Weight (ca.)
436 g
Front Wing – Material
Full Carbon (with core)
Front Wing – Connection
T6
